Name: USB to DMX Converter - Ravers Co
SKU: 1005001620687525
Availability: InStock
Rating: 4.50 (2 reviews)

Can be used on windows XP, Vista, windows7, windows 8, windows 10 ( 32bit and 64bit ), Windows 11, Mac OS, Android, and Linux.
USB RS485 converter
Chip: FT232RL+SP485
300 ~ 3Mbps baud rate
Up to 5km distance transferring
half duplex, non-isolated
ESD protection optional
Internal EEPROM with writable area
support Vendor ID re-write, support Mprog3.5
Support FTDI VCP driver and D2XX driver
Freestyle software (Go to freestyler website to download it), installation video is available.

Feature:
✔ USB A male metal shell to Din 3pin female adapter cable.
✔ USB DMX Interface.
✔ Micro processor enabled.
✔ Supports Freestyle software.
✔ DMX512 times configurable.
✔ Support for Windows XP, Vista, Windows 7, Windows 8, Windows 10 ( 32bit and 64bit ).
✔ The CD includes drivers, installation video (Freestyle software please go to freestyler.be to download it)
.

SPECIFICATIONS

Package: Yes
Model Number: USN201020B
Type: Serial Cable
Brand Name: YIDAMA-TONGLE
Certification: CE, RoHS
Feature: rs485
Connector Type: USB DMX
chip: FTDI
Gender: Male/female optional
OD: 4.0
Wire gauge: 26AWG
Material: PVC jacket + bare copper
System Support: Win7/8/10/XP/android/mac os/vista
Warranty: 1 Year
Material: PVC jacket+ bare copper wires
Caple length: 1.0m/3.2ft 1.8m/6ft, 3.0m/9.8ft, 5.0m/16ft
Package size: 14.5 * 10.8 * 3cm
Package weight: 112g/3.96oz

Software Installing Note:
Please follow the instructions to install the driver and software carefully, if you have any problems during installation, please feel free to contact us, we will try our best to solve it ASAP.

Package list:
1 x USB to DMX Interface Adapter
1 x CD
